MACHINE OVERVIEW
F
G
1
3
7
2
4
1. ON/OFF SWITCH
2. RIVING KNIFE
3. BLADE GUARD
4. BLADE
5. BEVEL LOCKING KNOB
6. RISE AND FALL/BEVEL ADJUSTMENT
HAND WHEEL
7. RIP FENCE SCALE MAGNIFIER
8. RIP FENCE LOCKING HANDLE
14
5
8
6
9
9. PUSH STICK
10. RIP FENCE
11. REAR CANTILEVER BRACES
12. ANTI-BOUNCE DEVICE
13. SLIDING MITRE FENCE
14. DUST PORT
15. DUST HOSE
16. REAR DUST PORT
17. BLADE CHANGE SPANNERS
11
15
10
11
12
17
16
13
