Matrix MAGNUM Serie Handbuch Seite 7

STORAGE AREA
0.63
m
(24.6ʺ)
2.32
(91.4ʺ)
Step 1 Hardware
1
Description Qty
A Bolt (M10x25L) 6
A
FREE AREA
m
0.6 (2 )
m ft
wide path
Step 2 Hardware
2
Description
A Bolt (M10x25L)
A
Step 3 Hardware
3
Qty
6 A
B
C
MG-A528
Description Qty
Bolt (M10x25L) 16
Repeat for
Flat Washer (M10) 16
each tier
Nut (M10) 16
C B A
7
