UNPACKING
Thank you for purchasing a MATRIX Fitness product. It is inspected before it is
packaged. It is shipped in multiple pieces to facilitate the compact packaging of the
machine. Prior to assembly, confirm all the components by matching them with
the exploded diagrams. Carefully unpack the unit from this box and dispose of the
packing materials in accordance with your local laws.
TOOLS REQUIRED FOR ASSEMBLY (not included)
3MM L-Shaped Allen Wrench
4MM L-Shaped Allen Wrench
5MM L-Shaped Allen Wrench
6MM L-Shaped Allen Wrench
8MM L-Shaped Allen Wrench
If any items are missing please contact your country's local MATRIX dealer for assistance.
0 10 20 30 40 50
mm
CAUTION
To avoid injury to yourself and prevent damage to the frame components, be sure
to have proper assistance removing the frame pieces from this box. Please be sure
to install the equipment on a stable base, and properly level the machine. Ensure
a minimum clearance width of 0.6 meters (24") for access to and passage around
MATRIX strength equipment. Please note, 0.91 meters (36") is the ADA recommended
clearance width for individuals in wheelchairs.
10MM L-Shaped Allen Wrench
Phillips Screwdriver
8MM Open-End Wrench
17MM Open-End Wrench
Guide Rod Lubrication
