3. Layout, Connections & Jumper Settings

3.1 Layout

7-48V T-Block for
optional external
Power Supply
Power LED
1x USB 2.0
Upstream B-Port

3.2 Connections

+7V - 48V T-Block:
GND (Ground)
+7V - 48V
USB 2.0 A-Port:
© Copyright 2020 by EXSYS Vertriebs GmbH. All Rights Reserved
7x USB 2.0
Downstream A-Port
ATTENTION!!!
Never connect power to GND, it will destroy
your Hardware!!!
USB 2.0 A-Port
Pin
Signal
1
VCC
2
DATA-
10
EX-1179HMVS
Pin
Signal
3
DATA+
4
GND
