REPLACEMENT OF BULB
(CODE 11BX5-11FMX5)
1. HELIOSA 11
1
2. UNSCREW THE 4 SCREWS ON THE BACK AND REMOVE
THE 2 SIDE COVERS AND THE 2 FRONT COMPONENTS OF
THE REFLECTOR.
2
3. ESTRACT THE BULB FROM THE SPRING CLIPS
3
4. REMOVE THE 2 BULB EXTREMITY HEAT-ELASTIC CAPS
AND DISCONNECT THE TWO FASTONS CONNECTING
CORDS TO THE BULB. IF THE CAPS USED DISPLAY SIGNS
OF WEAR AND TEAR, THESE MUST BE REMOVED BY
CUTTING THE CORDS NEXT TO THE 2 FASTONS.
4
4
17
ENGLISH
If necessary, call our Technical
Service. Technical Office tel.
02/90639261
