Press the Reloop Button -14- for the player to return to the last played loop. To exit the loop, press
the Loop-Out Button -13- again.
>>For more information about looping please see the chapter „Sampling".
15. CuE/Sample Banks 1-4
When in play mode, the Cue/Sample Banks 1 to 4 -15- can be used as hot cue buttons. Once sam-
pler mode has been activated by using the Sampler Button -17- the player will play samples from
the banks simultaneously to playback. For every bank, a 5-second sample can be saved and played
back. Press one of the respective Bank Buttons 1 to 4 to trigger the previously stored cue points or
samples.
>>For more information about looping please see the chapter „Sampling".
16. Memory Button
Use the Memory Button -16- to assign and store loops on the four sample banks. After creating
a loop with the help of the Loop-In and Loop-Out Buttons -12, 13-, press the Memory Button -16-.
The Memory LED goes on. Then select one of the four sample banks to store the loop on the very
same. The respective sample bank goes on. The Memory LED goes out. Repeat this process to
replace the respective sample or to record a new one. Via the memory function it is also possible
to permanently save cue points and samples for up to 500 CDs. For further information please see
the chapter "Sampling".
17. Sampler Button
To activate sample mode, press the Sampler Button -17-.
NOtE:
there are two different sample play modes: Endless Mode and One-Shot Mode. Endless Mode is ac-
tivated by pressing the Sampler Button - 17 - once; the sampler LED is continuously illuminated.
In Endless Mode the sample is played endlessly in a loop. One-Shot Mode is activated by pressing
the Sampler Button -17- a second time. the sampler LED flashes. In One-Shot Mode the sample
is triggered only once. If sample mode has been activated, the loops previously stored on sample
banks 1 - 4 -15- can be played simultaneously during CD playback.
18. Jog Wheel
The CD player features an extra large Jog Wheel -18- for authentic vinyl-like feeling while spinning. For
scratch applications the Jog Wheel -18- has been divided into two sections. The middle section is touch-sen-
sitive and responds similarly to a record on a turntable. The outer rubberized section is used for the pitch
bend function – similar to the edge of a turntable. If the Scratch function -10- is deactivated, the whole Jog
Wheel -18- can be used as search and pitch bend wheel. If you are in cue and pause mode you can search for
a cue point via precise frame search (1/75 min.) by turning the Jog Wheel -18- clockwise or counterclockwi-
se. In play mode the Jog Wheel -18- is used for the pitch bend function, similar to a turntable. This results
in a quick increasing (Push Start) or decreasing (Stop) of the pitch value. The faster the Jog Wheel -18- is
turned, the faster the pitch bend function will be. The same can be done via the Pitch Bend Buttons -24-.
19. Eject Button
To insert a CD, carefully slide the CD with the label facing upward into the slot -1-. The CD will be
pulled in automatically. The Status LED above the drive flashes while loading the CD. As soon as
the CD has been read and recognized, the Status LED goes out. When playing CDs with a diameter
of less than 12 cm, use a standard adapter. Press the Eject Button -19- to eject the CD.
20. pitch range Button
Press the Pitch Range Button -20- to select a pitch range of +/- 4%, +/-8%, +/-16% or +/-100%.
21. Key Lock Button
When activating the Key Lock function via this button -21- the track's original tone pitch, regard-
less of the set pitch, will be maintained. Press the button a second time to deactivate the Key Lock
function.
22.pitch Fader
Use the Pitch Fader -22- to infinitely change the pitch of the track within the selected range. The
difference from the original pitch is shown on the display -11F- in percent. In the pitch ranges +/-
4% and +/-8% a variation of 0.05% steps is carried out, in the pitch range +/-16% a variation of
0.02% steps is carried out and in the pitch range +/-100% steps of 0,1% will be carried out.
23. pitch On/Off Button
