Ambient temperature range:
-50 °C < t
< 50 °C
amb
-58 °F < t
< 120 °F
amb
Note: If operated consistently at or near MOPD,
the service interval will decrease.
Warning
Never switch on
power to the coil
when the coil is
dismounted from the
valve. Otherwise the
coil may be damaged
and there is risk of
injuries and burns.
2
Media temperature range
-50 °C < t
< 60 °C
media
-58 °F < t
< 140 °F
media
Clip-on coil
A
en-gb
The gasket
must be
exchanged,
if the valve is
dismantled
A:
New
B:
Used
DKRCC.PI.VA1.G4.53 / 520H7238
(en-gb) Do not insulate
(da) Må ikke isoleres
(de) Nicht isolieren
(fr) Ne pas isoler
(es) No encerrar para
evitar condensación
R744, R22/R407C, R404A/R507, R410A, R134a, R407A, R23.
Refrigerants
For other refrigerants, please contact Danfoss.
AKVH 10-0
AKVH 10-1
AKVH 10-2
Max. working
AKVH 10-3
pressure
AKVH 10-4
AKVH 10-5
AKVH 10-6
Max. test pressure
Max. differential pressure
B
da
de
Pakningen
Bei Zerlegung
skal skiftes,
des Ventils muß
hvis ventilen
die Dichtung
adskilles
usge wechselt
werden.
A:
A:
Ny
Neu
B:
B:
Brugt
Gebraucht
PS = 90 barg / MWP = 1305 psig
PT = 129 barg / 1870 psig
MOPD = P
- P
= 35 bar / 505 psi
1
2
75 Nm
45 Nm
fr
es
Es preciso
Changer le
joint chaque
cambiar la
fois que la
junta si se
vanne est
desmonta la
démontée
válvula
A:
A:
Neuf
Nueva
B:
B:
Usagé
Usado
