1.2 Specifications
Platform
• Mini-ITX Form Factor
• Solid Capacitor design
CPU
• Supports Socket FM2+ 95W / FM2 100W processors
• Digi Power design
Chipset
• AMD A68H (Bolton-D2H)
Memory
• Dual Channel DDR3 Memory Technology
• 2 x DDR3 DIMM Slots
• Supports DDR3 2400+(OC)/2133/1866/1600/1333/1066
non-ECC, un-buffered memory (see CAUTION 1)
• Max. capacity of system memory: 32GB
(see CAUTION 2)
• Supports Intel
• Supports AMD Memory Profile (AMP) up to AMP 2400
Expan-
• 1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)
sion
* PCIE 3.0 is only supported with FM2+ CPU. With FM2
Slot
CPU, it only supports PCIE 2.0.
• Supports AMD Dual Graphics
Graphics
• Integrated AMD Radeon
A-series APU
• DirectX 11.1, Pixel Shader 5.0 with FM2+ CPU. DirectX
11, Pixel Shader 5.0 with FM2 CPU.
• Max. shared memory 2GB
• Three graphics output options: D-Sub, DVI-D and HDMI
• Supports Triple Monitor
• Supports HDMI with max. resolution up to 4K × 2K
(4096x2160) @ 24Hz
* Only FM2+ APU can support up to 4096x2160 resolution
display via HDMI port
• Supports Dual-link DVI-D with max. resolution up to
2560x1600 @ 60Hz
• Supports D-Sub with max. resolution up to 1920x1200 @
60Hz
manuals search engine
®
Extreme Memory Profile (XMP) 1.3 / 1.2
TM
R7/R5 Series Graphics in
