I/O Panel
No. Description
1
2
3
4
5
6
* It is recommended to install the USB Keyboard/Mouse cable to USB 2.0 ports (USB01 or
USB23) instead of USB 3.0 ports.
** There are two LEDs on the LAN port. Please refer to the table below for the LAN port LED indica-
tions.
ACT/LINK LED
LAN Port
Activity / Link LED
Status
Off
Blinking
On
Downloaded from
www.Manualslib.com
1
2
11
10
USB 2.0 Ports (USB01)*
D-Sub Port
LAN RJ-45 Port**
Line In (Light Blue)
Front Speaker (Lime)***
Microphone (Pink)
SPEED LED
Description
No Link
Data Activity
Link
manuals search engine
3
9
8
7
No. Description
7
USB 2.0 Ports (USB23)*
8
USB 3.0 Ports (USB3_01)
9
HDMI Port
10
DVI-D Port
11
PS/2 Mouse/Keyboard Port
Speed LED
Status
Description
Off
10Mbps connection
Orange
100Mbps connection
Green
1Gbps connection
A68M-ITX
4
5
6
3
