Storage
• 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,
RAID 1 and RAID 10), NCQ, AHCI and Hot Plug
Connec-
• 1 x Chassis Intrusion Header
tor
• 1 x CPU Fan Connector (4-pin)
• 1 x Chassis Fan Connector (4-pin)
* CPU_FAN1 and CHA_FAN1 can auto detect if 3-pin or
4-pin fan is in use.
• 1 x 24 pin ATX Power Connector
• 1 x 8 pin 12V Power Connector
• 1 x Front Panel Audio Connector
• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Sup-
ports ESD Protection (ASRock Full Spike Protection))
• 1 x USB 3.0 Header by ASMedia ASM1042A (Supports
2 USB 3.0 ports) (Supports ESD Protection (ASRock
Full Spike Protection))
BIOS
• AMI UEFI Legal BIOS with GUI support
Feature
• Supports "Plug and Play"
• ACPI 1.1 Compliant wake up events
• Supports jumperfree
• SMBIOS 2.3.1 support
• DRAM, VDDP, SB Voltage multi-adjustment
Hardware
• CPU/Chassis temperature sensing
Monitor
• CPU/Chassis Tachometer
• CPU/Chassis Quiet Fan
• CPU/Chassis Fan multi-speed control
• CASE OPEN detection
• Voltage monitoring: +12V, +5V, +3.3V, Vcore
OS
• Microsoft
64-bit / 7 32-bit / 7 64-bit
* For the updated Windows
ASRock's website for details: http://www.asrock.com
* Carrizo FM2r2 processor supports Windows
8.1 64-bit / 7 32-bit / 7 64-bit only.
manuals search engine
®
®
Windows
10 32-bit / 10 64-bit / 8.1 32-bit / 8.1
®
10 driver, please visit
®
10 64-bit/
