5 Elektroanschluss vorbereiten
5
Prepare power supply
7
Stromanschluss mit Deckel wasserfest verschließen
und Gerät auf den Rahmen montieren
7
Power supply has to be sealed water proofed
with lid. Install unit on frame.
Mutter
Wandhalter /
Wheel nut wall
bracket
Schraube 4,5 x 60
Screw 4,5 x 60
M5 UScheibe
Dichtung ⅜"
M5 Flat washer
Washer ⅜"
6 Elektroanschluss in Anschlussdose montieren
6
Installing power supply on connecting box
Euroklemme 2000/4
3pole connection
terminal 2000/4
Kabelbinder /
Wiring tie
Schutzschlauch
Protection hose
Spritzwasserschutztülle
Water splash
protection sleeve
Kabelsatz RDX
Set of wiring RDX
8 Fertig!
8
Ready for use!
