fic size of screw is selected with Forward/Reverse switch (Figure
the set-collar (Figure 1). The cor- 4)
rect torque depends on several fac-
With the slide switch above the
tors:
On/Off switch you can select the
on the type and hardness of direction of rotation of the battery-
material in question powered drill/screwdriver and secu-
on the type and length screws re it against being switched on
used accidentally. You can choose bet-
on the requirements needing to ween clockwise and anticlockwise
be met by the screwed joint. rotation. To avoid causing damage
to the gearing it is advisable to
The clutch disengages with a gra-
change the direction of rotation
ting sound to indicate when the set
only when the tool is at a standstill.
torque is reached.
The On/Off switch is blocked when
the slide switch is in centre positi-
Selecting drill or hammer mode
on.
(Figure 1)
For normal drilling, turn the front
On/Off switch (Figure 5)
set-collar to the „drill" symbol. For
Infinitely variable speed control is
drilling with hammer action, turn
possible with the On/Off switch.
the front set-collar to the „hammer"
The further you press the switch,
symbol and the set-collar for torque
the higher the speed of the battery-
adjustment to the „drill" symbol. In
powered drill/screwdriver in accor-
this setting the slip clutch is inac-
dance with whichever gear has
tive. The maximum torque is availa-
been selected.
ble in drilling mode.
Changing over from 1st gear to
Screwdriving
2nd gear (Figure 2)
We recommend using self-cente-
You can work at a higher or lower
ring screws (e.g. Torx screws,
speed depending on the position of
recessed head screws) designed
the selector switch. To avoid dama-
for reliable working. Be sure to use
ging the gear unit you should only
a bit that matches the screw in
change over gears when the tool
shape and size. Set the torque, as
has stopped.
described elsewhere in these ope-
rating instructions, to suit the size
of screw.
