Bitronvideo MV104 Benutzerhandbuch Seite 11

EXTERNAL DOOR OPENER
1)
- PORRE IL PONTICELLO [ JUMPER ] PRESENTE VICINO ALLE MORSETTIERE
NELLA PULSANTIERA VIDEOCITOFONICA, SULLA POSIZIONE " MONO "
- THIS DIAGRAM IS ALSO VALID FOR COLOUR TV CAMERA AND MONITOR
- PLACE THE JUMPER NEXT TO THE TERMINAL BOARDS IN THE VIDEO PANEL ON " MONO "
- SCHEMA VALABLE AUSSI POUR CAMERA ET MONITEUR COULEUR
- PLACER LE PONTET PRES DES BORNIERS DE LA PLATINE VIDEO, EN POSITION " MONO "
Downloaded from www.Manualslib.com
PULSANTIERA
VIDEOCITOFONICA
VIDEO PANEL
PLATINE VIDEO
GV4/70 – AN 5126
GVC4/70 – AN 6108
MONO
F
V
+
TA
-
0
A +
0
A -
AP
A V
A F
APRIPORTA ESTERNO
OUVERT EXTERIEUR
NOTE - NOTES
- SCHEMA VALIDO ANCHE CON TELECAMERA E MONITOR A COLORI
manuals search engine
TASTO CHIAMATA AL PIANO
CALL BUTTON AT THE FLOOR
EVENTUELLE D'APPEL A L'ETAGE
SERRATURA
LOCK
SERRURE
10
012175526.14
MONITOR
MONITEUR
MV104 – AN8484
MVC104 – AN8492
P
IN
OUT
8
U
V
F
-
+
X
X
TRASFORMATORE
TRANSFORMER
TRANSFORMATEUR
T4 DIN – AN 0762
240
RETE
220
24
MAINS
110
24
SECTEUR
0
