No.
Description
1
CPU Fan Connector (CPU_FAN1)
2
Addressable LED Header (ADDR_LED1)
3
RGB LED Header (RGB_LED1)
4
Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
5
2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
6
ATX Power Connector (ATXPWR1)
7
SATA3 Connectors (SATA3_1_3)
8
SATA3 Connectors (SATA3_2_4)
9
USB 3.2 Gen1 Header (USB3_4_5)
10
System Panel Header (PANEL1)
11
USB 2.0 Header (USB_3_4)
12
Clear CMOS Jumper (CLRCMOS1)
13
Chassis/Water Pump Fan Connector (CHA_FAN2/WP)
14
Chassis Speaker Header (SPEAKER1)
15
Front Panel Audio Header (HD_AUDIO1)
16
ATX 12V Power Connector (ATX12V1)
