42 AVENTICS | RAK | R402005099–BDL–001–AB
2
1
Fig. 6: Angle adjustment
Table 1: Angle adjustment range
Angle
Minimum oscillation angle
Reference stopper, fine adjustment
Angle adjustment stopper, fine adjustment
Angle adjustment stopper at max. angle
Mounting interval
Maximum oscillation angle, size 2 – 4
Maximum oscillation angle, size 5S
Maximum oscillation angle, size 5D
Maximum oscillation angle, size 6S
Maximum oscillation angle, size 6D
Maximum oscillation angle, size 7S
Maximum oscillation angle, size 7D
Maximum oscillation angle, size 8S
Maximum oscillation angle, size 8D
3
5
Adjustment
°
30
°
±3
° °
-9 to +6
° °
-9 to +3
°
15
°
180
°
270
°
90
°
280
°
90
°
270
°
90
°
180
°
90
4
00133582
Fig. 6,
referenc
e
1
2
3
3
4
5
5
5
5
5
5
5
5
5
