HomeMatic HMW-IO-12-Sw14-DR Montage- Und Bedienungsanleitung Seite 35

Terminal Function
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
2.1
2.2
2.3
2.4
2.5
2.6
2.7
2.8
3.1
3.2
3.3
3.4
3.5
3.6
Downloaded from www.Manualslib.com
Shared connection (common) relay output
1,2,3
Digital output 1
RS485 bus, cable A
Supply voltage, +24 V
Relay output 1
Digital output 2
RS485 bus, cable B
Supply voltage, ground (GND), ground
reference for all inputs
Relay output 2
Digital output 3
Digital input I7
Analogue input I1
Relay output 3
Digital output 4
Digital input I8
Analogue input I2
Relay output 4
Digital output 5
Digital input I9
Analogue input I3
Relay output 5
Digital output 6
manuals search engine
Installation
35
