Migatronic FOCUS TIG 200 AC/DC Kurzanleitung Seite 4

11
4
5
12
10
2
18
15 16 17
13
14
9 7 8
1 Welding current
Press the key and turn the control knob
to set the welding current.
2 Welding voltage
The LED shines when there is voltage
on MMA electrode or TIG torch.
3 Parameter units
The LED shines when the relevant para-
meter unit is active.
4 Overheating indicator
The LED shines when the machine is
overheated.
Downloaded from www.Manualslib.com
5 Mains error
The LED shines if the mains voltage is
3
too high or too low.
6 Welding process
1
Choice of MMA/TIG.
7 Trigger mode
Choice of 2-stroke/4-stroke.
8 Current adjustment
Choice of torch adjustment.
6
9 Ignition method
Choice of HF/LIFTIG ® ignition.
10 Gas pre flow (time)
11 Slope down
Time from welding current to stop
amp.
12 Gas post flow (time)
13 Pulse
Key activated = pulse.
14 Pulse setting
Press the menu key until the LED shines
at:
manuals search engine
QUICKGUIDE FOCUS TIG 200 AC/DC
15 Current type
Choice of AC or DC welding.
16 AC-t-balance, time-based
Time balance between positive and
17 AC-electrode preheating
Automatic electrode preheating.
18 Choice of secondary parameters
Opens parameters 10, 11 and 12.
