ENGLISH
Steps 1 , 2 , 3 and 4: the procedure requires the choice of the menu language, country of use
and, PIN setting and time zone. Press the arrow key ► to continue.
Step 4: TV connection to the Internet network necessary to use the connected Smart / TV
functions. If the Ethernet cable has already been connected to the TV's RJ45 port, the
connection to the home modem/router will take place automaticallyl. If it is not possible,
configure the Wireless connection using the arrow keys and ENTER on the remote control:
Use Wi-Fi network
select the item , choose your own Wi-Fi network from the list of detected
networks, type the correct network password very carefully (press ENTER to bring up the
Connect
virtual keyboard), then select the item. Finally press the arrow key ► to go to the
next step.
Step 5: To download the application, simply frame the QR code visible on the screen with
the appropriate QR/video camera of your mobile device, then proceed with the installation.
ATTENTION!
Make sure that your mobile device and Smart TV are connected to the same home data
network.
The application does not totally replace the traditional remote control, it is mainly designed
to control the Smart features of the TV (applications, media player, etc. ...)
Some IP applications require the use of a keyboard and/or a cursor/mouse; in this case, the
traditional remote control supplied with the TV is not sufficient to control them.
Step 6: choose the user's favorite mode / source. In particular

Main functions

Digital TV mode
if you have selected the TV mode, you need to scan a digital TV channel. To access the
Antenna Type between Digital Terrestrial (DVB-T / T2), Cable (DVB-
Channel menu, set the
Digital Satellite
C) or (DVB-S / S2), make sure that the corresponding antenna cable is
correctly connected, define the search parameters and proceed with the scan.If you opt for
automatic scanning of digital TV, the TV will propose that you upload a list of Italian satellite
default channels with a typical arrangement of the TivùSat platform channels.
NOTE
The viewing of the encrypted TivùSat channels requires the use of a dedicated conditional
access module (CAM) and card (Smart-card), to be purchased separately.
Due to frequent satellite channel updates, the default satellite channel list may contain
obsolete channels and may not coincide exactly with the TivùSat channel list.
Once the selected frequencies have been scanned, the TV will create the channel list with
the defined arrangement (e.g. the LCN one, corresponding to the numbering requested by
the terrestrial channel issuers).
If you want to proceed with the scanning of different input/antenna channels, proceed as
described above choosing the corresponding type of antenna desired (different from the
previous one). The different available channel lists will then be available only if the TV is in
the correct TV section (terrestrial/cable/satellite). In particular, to switch from viewing a
terrestrial channel to a satellite channel, press the MENU button, enter the Channel menu
