TELE System
Product description
Connections
The following inputs and outputs are available behind the TV:
1.
USB (x2): USB2.0 ports for connecting USB mass storage devices for multimedia
playback (Media player function).
2.
Headphone : headphone output (3,5mm jack).
3.
CI/CI+ : housing for CI/CI + common interface modules.
4.
COAXIAL : coaxial digital audio output.
5.
HDMI1 , HDMI2 , HDMI3 : HDMI digital audio-video inputs (v.1.4) for connecting an
external AV source (e.g. a receiver or DVD player) equipped with an HDMI interface.
6.
RF IN (T2/C) : antenna input (IEC type) for receiving digital terrestrial (DVB-T / T2) or
cable (DVB-C) signal.
7.
RF IN (S2) : SATELLITE RF Antenna input (type F).
8.
SCART/RCA : analogue audio-video input for connecting an AV device with a RCA (CVBS
+ Stereo Audio) interface.
9.
PC Audio IN and PC VGA : audio inputs (3.5mm jack) and video (VGA) for connecting a
Personal Computer.
10. LAN : Ethernet (RJ45) port for connection to the Internet, necessary for the Smart TV
function.
11. Supply : integrated power cable for connecting the television to the 230VAC, 50Hz
mains supply.
Batteries
You must insert the batteries (not supplied) when the product is purchased; it is instead
necessary to replace them once the remote control no longer works properly.
First open the appropriate cover on the back of the remote control. Then to replace the
batteries, introduce the 2 AAA batteries into the compartment respecting the correct
polarity as indicated; instead, to remove batteries, remove the dead batteries from the
compartment and dispose of the batteries separately from household waste and take them
to any point of sale or collection.
WARNINGS
To prevent corrosive liquid leakage from damaging the remote control, it is advisable to
remove the batteries if you believe you will not use the device for a long time.
Avoid using different types of batteries such as new and used batteries at the same time.
First installation
Before switching on the television, it is advisable to connect the aerial cable (terrestrial
and/or satellite) and the ethernet cable (if available). In this way, thanks to the installation
wizard, you can start using your Smart TV by performing a few simple steps briefly
described below:
