programme
Downloaded from www.Manualslib.com
P1 drying
P2 slow biscuit
P3 fast biscuit
P4 glaze 1050°C
P5 glaze 1180°C

Starting a Firing

P
1
flashing
manuals search engine
heat up heat up
time (t1) Temp. (T1)
5:00 150
6:00 600
4:00 600
2:00 400
2:00 400
Keep in mind that the programme values shown above
only apply if you haven't changed them !
The following example demonstrates how to start a
slow biscuit firing by calling up programme P2.
After turning on the PYROTEC D1 the display (1)
reads the actual kiln temperature.
5
Press key (11) again and again until the indicator
4
3
points to P2 (as depicted on the left hand side).
2
Display (1) now reads the firing temperature of
¡C
programme P2 (returns to kiln temperature after 15
seconds).
h : min
Press key (12) to start the firing. Display (1) reads the
¡C
actual kiln temperature during the entire firing. Every
h : min
20 seconds the firing temperature is shown flashing.
The flashing decimal point on the right hand side of
display (1) always indicates a running programme.
The indicator in the firing curve (9) points to the
current programme segment (example shows heating
up in segment (a) of the firing).
firing dwell
Temp. (T2) (t2)
150 0:00
900 0:10
900 0:10
1050 0:20
1180 0:20
Note
