General Information

Your PYROTEC D1 uses the latest technology
available concerning firing safety, accuracy and easy
handling. Appearing as a handy controller easy to use,
it is a highly sophisticated instrument with a totally
configurable control design allowing adaption to
almost all applications. Reading through this manual
quickly familiarizes you with the numerous features of
your PYROTEC D1.
Please also refer to the safety advise of your kiln
manufacturer. Make sure that the control is placed at a
proper distance from the kiln and is not exposed to
direct heat or radiation from the kiln.
Depending on the kiln model the controller is either
mounted on the kilns operating panel or on the wall
(use mounting bracket coming with the kiln).
Note: Never place the PYROTEC D1
controller on the top of your kiln !
Your PYROTEC kiln and controller has passed
extended tests during the manufacturing process.
However, we strongly recommend never to fire the
kiln unattended especially at the end of the firing.
Setting up the
Mount the PYROTEC D1 controller on the kilns resp.
the wall accordingly. The controller is connected to
Controller
the kiln by a multipole plug (fits only in one orienta-
tion). Lock the plug by the lever on the socket.
When turning on the controller with the mains switch
(5) after 3 seconds display (1) shows the actual kiln
temperature. Your PYROTEC D1 is now ready for use.
