Boffi eclipse RERX07 Montage- Und Serviceanleitung Seite 3

RERX07 I
30mm
1" 3/16
14,5mm
37/64"
9,5mm
3/8"
9,5mm
3/8"
35mm
1" 3/8
RERX08 I
30mm
1" 3/16
14,5mm
37/64"
9,5mm
3/8"
9,5mm
3/8"
35mm
1" 3/8
Dimensioni d'ingombro e quote di fissaggio
Overall dimensions and fixing points
Dimensions d'encombrement et fixations
Maßen und Befestigungshöhe
270mm
10" 5/8
1/2" GAS (EU)
1/2" NPT (USA)
1/2" GAS (EU)
1/2" NPT (USA)
100mm 100mm
3" 15/16 3" 15/16
270mm
10" 5/8
106mm
4" 11/64
1/2" GAS (EU)
1/2" NPT (USA)
1/2" GAS (EU)
1/2" NPT (USA)
100mm 100mm
3" 15/16 3" 15/16
14,5mm
37/64"
114mm
4" 31/64
35mm 17mm
1" 3/8 43/64"
MIN.
91mm
3" 37/64
MAX.
109mm
4" 19/64
35mm
1" 3/8
14,5mm
37/64"
114mm
4" 31/64
35mm 17mm
1" 3/8 43/64"
MIN.
91mm
3" 37/64
MAX.
109mm
4" 19/64
35mm
1" 3/8
-3-
20,5mm
13/16"
52mm
2" 3/64
62mm
2" 7/16
20,5mm
13/16"
52mm
2" 3/64
62mm
2" 7/16
