Caratteristiche di funzionamento
Pressione di servizio ideale: ..................... 3 bar
Pressione di servizio massimo: ............................ 5 bar
Temperatura acqua calda ideale: ........................ 60° C
Temperatura acqua calda massima: ................... 70° C
Attenzione:
Risciacquare bene le tubazioni prima del montaggio.
F
Caractéristiques de fonctionnement
Pression de service idéale: ...................... 3 bar
Pression de service max.: .................................... 5 bar
Température idéale de l'eau: ............................... 60° C
Température max. de l'eau: ................................. 70° C
Attention:
Rincer à fond la tuyauterie avant le montage.
RERX07 E
RERX08 E
RERX17 E
RERX18 E
197mm
7" 3/4
48mm
1" 57/64
Dimensioni d'ingombro e quote di fissaggio
Overall dimensions and fixing points
Dimensions d'encombrement et fixations
Maßen und Befestigungshöhe
52mm
2" 3/64
62mm
2" 7/16
L. 1500mm
L. 59" 1/16
37mm
1" 29/64
Ø60mm
Ø2" 23/64
Ø80mm
Ø3" 5/32
GB
Operating data
Ideal operating pressure: .......................... 3 bar
Max. operating pressure: ...................................... 5 bar
Ideal water temperature:...................................... 60° C
Max. water temperature:...................................... 70° C
Attention:
Before installation flush pipes thoroughly.
D
Betriebsdaten:
Idealer Betriebsdruck: .............................. 3 bar
Max. Betriebsdruck: .............................................. 5 bar
Ideale Wassertemperatur: ................................... 60° C
Max. Wassertemperatur: ..................................... 70° C
Achtung:
Vor Montage die Leitungen gründlich durchspülen.
270mm
10" 5/8
Ø60mm
Ø60mm
Ø2" 23/64
Ø2" 23/64
Ø80mm
Ø80mm
Ø3" 5/32
Ø3" 5/32
-2-
114mm
4" 31/64
MIN.
91mm
3" 37/64
MAX.
109mm
4" 19/64
3mm
1/8"
53mm
2" 3/32
