Setting Up A Wlan Connection - FIESSLER RAZL-2CO Handbuch

People Counter RAZL-2CO (Translation)

2.11 Setting up a WLAN connection

The active sensor pillar provides a WLAN after switching on.
To set the maximum number of people allowed and to make other settings, a connection must be made once to this WLAN using a mobile device.
This can be, for example, a smartphone, tablet, notebook or any other WLAN-capable device that has an Internet browser.
Step 1: Select "WLAN" in the Settings menu of the mobile device.
Step 2: After a short time, all available WLAN connections are displayed.
Step 3: Select WLAN with the name "RAZL-serial number of the device" (the serial number of the device can be found on the nameplate)
Step 4: Enter preset WLAN password "fiessler#razl".
The WLAN password should be changed after the first connection (via Menu - Network Configuration)!
Step 5: A message may appear on the mobile device that an Internet connection is no longer possible.
It must be selected that the WLAN connection is retained.
If the mobile device is connected to this WLAN, an Internet connection with the mobile device is no longer possible until the connection to this
WLAN is terminated.
