CUS100ME Handbook
Power curves
100
90
80
70
60
50
40
30
20
10
0
-20
100
90
80
70
60
50
40
30
20
10
0
-20
*1)
- 50mm above surface
*3)
- Tested with airflow direction G (see Application Note)
- Best airflow direction is from top or sides. Customer to ensure airflow rate and direction to keep
components temperature below the limits.
*4)
- 50mm above surface, orientation A (see Application Note) no additional coldplate
*5)
- U chasses or Baseplate fixed on a coldplate (system chassis), orientation A (see Application Note)
- Temperature of CUS100ME chassis or Baseplate was less then ambient + 6°C.
Output Power vs Ambient Temperature
@ 90Vac to 264Vac, derate by 10% at 85Vac.
-10
0
10
20
Ambient Temperature [°C]
Output Power vs Ambient Temperature
@ 90Vac to 264Vac, derate by 10% at 85Vac.
Open frame and /B convection cooling, Orientation A *1)
/U - U chassis option, convection cooling *4)
/A - U chassis with top cover, convection cooling *4)
/U and /B - U chassis and Baseplate option, cold plate cooling *5)
/A - U chassis with top cover, cold plate cooling *5)
-10
0
10
20
Ambient Temperature [°C]
Page 17 of 24
Airflow 1m/s *3)
30
40
50
30
40
50
60
70
80
90
60
70
80
90
260423-3 Mar 2019
