ATX 12V Power
Connector
(4-pin ATX12V1)
(see p.1, No. 1)
Serial Port Header
(9-pin COM1)
(see p.1, No. 15)
TPM Header
(17-pin TPMS1)
(see p.1, No. 13)
This motherboard
provides a 4-pin ATX 12V
power connector.
This COM1 header
RRXD1
DDTR#1
DDSR#1
supports a serial port
CCTS#1
module.
1
RRI#1
RRTS#1
GND
TTXD1
DDCD#1
This connector supports Trusted
Platform Module (TPM) system,
which can securely store keys,
1
digital certificates, passwords,
and data. A TPM system also
helps enhance network security,
protects digital identities, and
ensures platform integrity.
B150M-PIO2
