Disassembly; Tapping And Commissioning (Only For Spigot Saddle) - FRIATEC VACUSET XL Bedienungsanleitung

7.
• After expiry of the fusion time, the electrofusion unit can be switched off and
the fusion cable can be removed.
• After expiry of the waiting time of at least 30 minutes, the compressor can
be switched off.
• Loosen and remove the hose connections, the plunger (only for spigot
saddle) and the manometer.
NOTICE
After the disassembly of the plunger, any Vaseline DAB10 residues at the
FRIALEN XL spigot saddle SA-XL are to be thoroughly removed; e.g. using a
suitable PE cleaning agent. Any entrainment of the lubricant into the fusion
areas is to be prevented.
• Protect the equipment and store it again in the transport box.
8.
Tapping of the spigot saddle is made using the FRIATOOLS drilling device
FWAB XL / FWAB ASA.
• The following waiting times are to be observed:
From fusion end to tapping
(under vacuum clamping)
From fusion end to tapping
(under vacuum clamping)
Downloaded from www.Manualslib.com

Disassembly

Tapping and commissioning (only for spigot saddle)

Cooling time in minutes for FRIALEN XL
saddle fittings SA-XL and RS-XL
30 minutes
Cooling time in minutes for FRIAFIT saddle fitting ASA-VL
10 minutes
manuals search engine
Up to pressurisation via the outlet
(CT)
60 minutes
Up to application of the test pressure
(0,5 bar) via the outlet (CT)
10 minutes
EN
