Receiver installation

! Before working on the installation, isolate all
electrical supplies. All electrical wiring must
be carried out by a qualified person.
For easier installation, the Thermoflash DIGI 24 HF
kit is suppplied with a flexible 4-wire 1,5 mm
cable of 1.20m length (not connected).
We recommend using this cable for connecting the
HF receiver according to the following colour
codes:
brown = phase
blue = neutral
à
gray
connection to the boiler
black
L
N
L
5 4 3 2
!
When two appliances (heating and cooling)
are connected, always keep one of them swit-
ched off to prevent their simultaneous opera-
tion during the same season.
2
L
N
N
1
L N
5 4 3 2 1
16
L
N
L N
5 4 3 2 1
