Setting current time
You are putting the device into operation for the
first time.
• You have just pressed the
RESET button.
• I2:00 appears and the pointer
L
flashes.
u
Set the time using the +/- buttons (the numbers
run off more quickly when the button is pressed
continuously).
Validate with the OK button.
If you wish to change the time or the day, press
the MODE button until the pointer
clock sign and continue as above for points
and .

Temperature setting

Comfort and reduced temperatures are pre-set:
Comfort = 20°C, Reduced = 16°C.
c
c
Modification of comfort temperature
Press the button.
Modify the temperature with the
Validate with the OK button.
Modification of reduced temperature
Press the button.
Modify the temperature with the
Validate with the OK button.
Programming
PROG
P1-P4
You can programme your DIGI 24 HF according to
4 programme settings: P1, P2
recorded and cannot be modified.
allows you to create a personalized programme.
P1 = Comfort temperature from 6 a.m. till 11 p.m.
Reduced temperature from 11 p.m. till 6 a.m.
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
!
P1 is the default allocation. If this corres-
ponds to your life style, stay in automatic
mode, otherwise, continue.
P2 = Comfort temperature from 6 a.m. till 8.30
a.m. and from 4.30 p.m. till 11 p.m.
Reduced temperature from 8.30 a.m. till
4.30 p.m. and from 11 p.m. till 6 a.m.
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
P3 = Comfort temperature from 6 a.m. till 8.30
a.m., from 11.30 a.m. till 1.30 p.m. and from
4.30 p.m. till 11 p.m.
Reduced temperature from 8.30 a.m. till
11.30 a.m. from 1.30 a.m. till 4.30 p.m. and
from 11 p.m. till 6 a.m.
0 1 2 3 4
P4 = Blank programme allowing you to
create 3 comfort temperature periods
and 3 reduced periods.
Selection of an existing P1, P2 or P3
programme (in programming mode all
modifications are automatically validated).
example : P2
L
under the
Press the
programming mode.
The N° of the programme assigned to the day
flashes on the right-hand side of the display panel.
Press the
programme number flashes in the right side of
the screen.
Validate with the
Creating a P4 programme
A 24-hour profile composed of 48 thermometers
+/- buttons. at the bottom of the display panel allows your
programme composition to be easily viewed;
A half-empty thermometer corresponds to
30 minutes at reduced temperature.
A full thermometer corresponds to 30 minutes
+/- buttons.
at reduced temperature.
example: programming 3 temperature periods:
6 a.m. till 8 a.m., noon till 2 a.m. and 6 a.m. till
22 a.m.
and P3 are pre-
P4 is blank and
0
From the Auto,mode press the
button.
Press the
programme number flashes in the right side of
the screen.Your display panel indicates time as
0:00 and the first thermometer flashes on the
24-hour profile.
5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
PROG P1-P4 button to go into
PROG P1-P4 button until the P2
OK button.
1
PROG P1-P4
button until the P4
PROG P1-P4
14
Press the button several times to obtain
6:00 :The time displayed advances by 30 minutes
for each short press. Continuous pressing ac-
celerates the time run-off.
• Press the button several times to obtain
8:00.
• Press the button several times to obtain
I2:00.
• Press the button several times to obtain
I4:00.
• Press the button several times to obtain
I8:00.
• Press the button several times to obtain
22:00.
N.B. : if you make a mistake (e.g. 11.30 instead of
12.00) use the +/- buttons to advance or return and
correct with the thermometer buttons.
Validate with the OK button.
Press the MODE button to return to Auto mode.
Programme reading
You can check your programming:
From Auto mode, press the
button.
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
Press the MODE button to return in Auto mode.

Automatic mode (Auto)

You pass into automatic mode by
pressing the MODE button until the
L
pointer appears under Auto.
In automatic mode the clock thermo-
stat adapts to your life style by running
the programs you have selected.
Manual mode (Manu)
Manual mode transforms your device into a simple
thermostat.
It allows you to maintain a constant temperature in
your dwelling (set to a temperature of between 5°C
and 30°C).
Auto Manu
¡c
Press the MODE button to position the pointer
L
under Manu.
Press the + or - buttons to adjust to the desired
temperature (for instance 22.5°C).
To quit the Manu mode, press the
L
and re-position under Auto.
PROG P1-P4
MODE
Auto Manu
°c
