5.2.2 Spare parts for Liquid End 8-channel

Pkg unit (A) 8 pc, pkg unit (B) 3 pc.
The appearance and dimensions of the spare parts correspond to the respective nominal volume.
1
Ill. 8: Shaft and seal, here 50 μl Liquid End
1
Seal
2
Shaft
Volume
1 - 50 μl
20 - 300 μl
*incl. 8 seals and 1 mounting tool
Liquid End 20-300µl with additional pressure ring.
Shaft change
If a shaft change is required, all shafts of a multiple-channel Liquid End must always be replaced!
Liquid Handling Station 9974 96
2
A*
7096 30
7096 32
NOTICE
Ordering Information
B
7033 43
7033 46
Operating manual English
