Fitting The Sensor To The Wf Mounting Drum Holder - Fronius OPT/i WF R Installationsanleitung Ersatzteilliste

Fitting the sensor
to the WF
MOUNTING Drum
holder
20
Downloaded from www.Manualslib.com
1
1
5
3
4
Remove the holder (1) from the sensor
3
3
Place the sensor on the spacer as shown
5
5
Adjust the sensor
manuals search engine
2
2
(1)
1
2
Attach the spacer supplied with the wire drum holder
to the underside of the wire drum holder
4
4
2 x TX25
M5 x 12 mm
Secure the sensor with the two M5 x 12 mm TX25
screws supplied with the wire drum holder
6
6
Set the "Delay"
1
1
2
3
4
