5. VGA Input is for connecting a personal computer to the TV set.
Connect the PC cable between the PC INPUT on the TV and the PC output on your PC.
Note: You can use YPbPr to VGA cable (not supplied) to enable YPbPr signal via VGA input.
WARNING: You cannot use VGA and YPbPr at the same time.
6. SPDIF Out outputs audio signals of the currently watched source.
Use an SPDIF cable to trasfer audio signals to a device that has SPDIF input.

Viewing the Connections - Side Connectors

1. The CI Slot is used for inserting a CI card. A CI card allows you to view all the
channels that you subscribe to. For more information, see "Conditional Access"
section.
2. Side USB input.
3. Video Input is used for connecting video signals of external devices.Connect
the video cable between the VIDEO IN socket on the TV and the VIDEO OUT
jack on your device.
4. Audio Inputs are used for connecting audio signals of external devices.
Connect the audio cable between the AUDIO INPUTS on the TV and the
AUDIO OUTPUT jacks on your device.
Note: If you connect a device to the TV via the VIDEO INPUT, you should also
connect your device with an audio cable to the AUDIO INPUTS of the TV to
enable audio.
5. The headphone jack is used for connecting an external headphone to
the system. Connect to the HEADPHONE jack to listen to the TV from
headphones.

Aerial Connection

• Connect the aerial to the

Power Connection

IMPORTANT: The TV set is designed to operate on 220-240V AC, 50 Hz.
• After unpacking, allow the TV set to reach the ambient room temperature before you connect the set to the
mains. Plug the power cable to the mains socket outlet.
AERIAL INPUT (ANT) socket located at the rear of the TV.
- 39 -
