AGR (Advance Graphics Riser) Slot
The AGR (Advance Graphics Riser) slot is a
special design that only supports compatible
AGP VGA cards.
MSI Reminds you...
If you want to install an add-on VGA card when you first use the mainboard...
1. Insert the add-on VGA card and connect the monitor cable on it.
2. Boot and Install the OS (includes the chipset driver) and add-on VGA card driver.
3. Install the on-board VGA driver.
4. Right-click the desktop. Choose Properties/Settings. Make sure that "Extend my Windows
desktop onto this monitor" is not checked.
If you want to install an add-on VGA card in the existing OS sometime later...
1. Remove the on-board VGA driver.
2. Turn off the system. Insert the add-on VGA card.
3. Connect the monitor cable to add-on VGA connector.
4. Boot and install the add-on VGA card driver.
5. Install the on-board VGA driver.
6. Right-click the desktop. Choose Properties/Settings. Make sure that "Extend my Windows
desktop onto this monitor" is not checked.
Compatible VGA Card List
VGA CARD
No.
1 Alvatron
2 ATI
3 ATI
4 GAINWARD GFX 5900 Ultra
5 Gigabyte
6 Gigabyte
7 Leadtek
8 Leadtek
9 MSI
10 MSI
11 MSI
12 MSI
13 MSI
14 MSI
15 MSI
16 MSI
17 MSI
Downloaded from www.Manualslib.com
Model name
Vender
FX5700U
Fire GL 8800
Radeon 9800 XT
GV-R9200
GV-N57L128D
Winfast A360LE TD
Winfast A400GT TDH GeForce 6800GT
MS-8863
MS-8907
MS-8911
MS-8919
MS-8923
MS-8931
MS-8936
MS-8936
MS-8946
manuals search engine
VGA Chip VGA Memory
GeForce FX5700 Ultra 128MB/DDR SDRAM
Fire GL 8800 128MB/SDRAM
Radeon 9800 XT 256MB/DDR SDRAM
GeForce 4 FX 5900 U 256MB/DDR SDRAM
Radeon 9200 128MB/DDR SDRAM
GeForce FX5700LE 128MB/DDR SDRAM
GeForce FX5700LE 128MB/DDR SDRAM
256MB/DDR SDRAM
GeForce 4 MX 460 64MB/SDRAM
GeForce FX 5200 64MB/DDR SDRAM
GeForce FX 5200 128MB/DDR SDRAM
GeForce FX 5200 128MB/DDR SDRAM
GeForce FX 5200 Ultra 128MB/DDR SDRAM
GeForce FX 5600 Ultra 128MB/DDR SDRAM
GeForce4 MX4000 64MB/DDR SDRAM
GeForce FX5500 128MB/DDR SDRAM
GeForce FX 5950 Ultra 256MB/DDR SDRAM
10
MS-7101
Result Driver Ver.
Pass 6.6.8.1
Pass 6.12.10.3056
Pass 6.14.10.6458
Pass 6.14.10.6681
Pass 6.14.10.6458
Pass 6.14.10.6172
Pass 6.14.10.6172
Pass 6.14.10.6172
Pass 6.14.10.2958
Pass 6.14.10.6172
Pass 6.14.10.6172
Pass 6.14.10.6172
Pass 6.14.10.6172
Pass 6.14.10.6172
Pass 6.14.10.6172
Pass 6.14.10.6172
Pass 6.14.10.6681
