• • ELECTRICAL CONNECTION
The appliance must be fitted correctly to
guarantee electrical safety. During fitting and
maintenance operations, the appliance must
be unplugged from the electrical grid. Fuses
must be switched off or removed.
The electrical connections are made before
the appliance is installed in its housing.
Ensure that:
- the electrical installation has sufficient
voltage,
- the electrical wires are in good condition,
- the diameter of the wires complies with the
installation requirements.
Your oven must be connected with a
(standard) power cable with 3 conductors of
1.5mm
be connected to a 220-240V
Downloaded from
www.Manualslib.com
18/12/2007
2 / INSTALLING YOUR APPLIANCE
220-240 V ~ Single-phase line
16A fuse or differential
circuit breaker
Electrical outlet
2 poles + + e e a a r r t t h h
standard CEI 60083
2
(1 live + 1 neutral + earth) which must
~
manuals search engine
15:01
Page 7
Single-phase 20A Meter
220-240V ~ 50Hz
Power
supply cable
length 1.50 m
approx.
grid by means of a 1 live + 1 neutral + earth
CEI 60083 standard power socket or via an
all-poles cut-off device in compliance with the
installation rules.
Warning
The safety wire (green-yellow) is
connected to the appliance's
and must be connected to the earth terminal
of the electrical set-up.
If the connection is to an electric wall socket,
it must remain accessible after installation.
The fuse in your set-up must be 16 amperes.
single-phase
7
EN
terminal
