PARTS LIST (See Hardware Identifier)
Item
Qty.
Part No.
1
1
800149
2
1
904811
3
1
903407
4
1
200188
5
1
202822
6
1
200117
7
1
203124
8
4
203063
9
2
906410
10
1
202662
11
12
203218
12
1
203220
13
1
200516
14
2
203798
15
22*
203100
16
1
203223
17
2
226401
18
1
200123
19
1
200512
20
5*
203232
21
1
206252
22
1
206948
23
1
203330
24
2
200122
25
2
900223
26
4
203103
27
2
226403
28
2
206940
29
4
206938
30
1
206956
31
1
204839
32
1
904816
33
1
904815
34
1
204813
35
2
203217
36
1
203679
37
2
201124
38
1
204814
P/N 214973A
04/03
Downloaded from
www.Manualslib.com
Description
Top Pole Section, Black
Middle Pole Section, Black
Bottom Pole Section, Black
Rod, Zinc 3/8 x 5-1/4 Long
Eyebolt, 3/8–16 x 3-3/4 Long
Tank
Stake, Tie Down
Lock Nut, Nylon Insert, 3/8–16
Struts, Base
Bolt, 5/16-18 x 4-1/2 Long
Washer, Flat, 5/16 x 7/8 O.D.
Lock Nut, Nylon Insert, 5/16-18
Vinyl, Bolt Cover, 5/16
Bolt, Hex Flange, 5/16-18 x 1-1/2 Long
Lock Nut, Whiz, 5/16-18
Bolt,Carriage 5/16-18 X 1.00" Long
Wheel 4" Diameter
Upper Pivot Bracket
Bolt, Hex Head,3/8-16 x 3-1/2 Long
Washer, 3/8 I.D., x 3/4 O.D.
Bolt, Hex Head, 3/8-16 x 1 Long
Lower Pivot Bracket
Bolt, Hex Head, 3\8-16 x 4-1/2 Long
Hinge Tubes
Wheel Bracket
Bolt, Carriage, 5/16-18 x 2 Long
Wheel 6" Diameter
Axle, .461 O.D. x 21 Long
Push Caps
Disc, Plastic, 5" O.D. x .0625 Thick
Tinnerman Nut
Inner Channel
Outer Channel
Handle, Height Adjustment
Bolt, Carriage, 5/16-18 x 1-1/2 Long
Bolt, Hex Head, 3/8-16 x 2 Long
Lock Nut, Hex, 3/8-16
Trigger, Height Adjustment
WARRANTY CARD:
Please remember to complete your product
registration form either
on-line at:
www.huffysports.com/warrantycard
or mail-in the enclosed postcard.
WARNING: IF YOUR SYSTEM IS EQUIPPED WITH AN ACRYLIC
BACKBOARD, EXAMINE BACKBOARD FOR ANY DAMAGE THAT MAY
HAVE OCCURRED DURING SHIPMENT. CRACKS IN THE BACKBOARD
COULD RESULT IN SUDDEN BREAKAGE. IF BACKBOARD IS
DAMAGED IN ANY WAY PRIOR TO OR AFTER ASSEMBLY, CALL TOLL-
FREE NUMBER FOR FREE REPLACEMENT:
U.S. 1-800-558-5234; CANADA: 1-800-284-8339;
http://www.huffysports.com
manuals search engine
Item
Qty.
Part No.
Description
39
1
203589
Bolt, Hex Head, 5/16-18 x 1-1/4 Long
40
1
201125
Ratchet Spring
41
1
211257
Label, Accuheight
42
1
206219
Cap, Tank-Black
43
2
204840
Pin, 3/8 x 3 Long
44
2
204841
Spring, Silver
45
1
204819
Bracket, Pole Mount
46
2
203053
Bolt, Carriage, 5/16-18 x 4 Long
47
1
206990
Reinforcement Bracket
48
1
204811
Spring Cover, Handle Left Side
49
1
204812
Spring Cover, Handle Right Side
50
1
206263
Bolt, Carriage, 5/16-18 x 3 Long
51
2
201129
Spacer, Metal, .5 O.D. x .402 I.D. x 1.8 Long
52
2
900846
Board Bracket
53
1
240017
Bolt, Hex Head, 1/4-20 x 2-1/4 Long
54
1
206360
Bolt, Hex Head, 3/8-16 x 2.625 Long
55
1
203493
Lock Nut, Hex Center-lock, 1/4-20
56
2
904821
Elevator Tube, Lower (Long)
57
6
204847
Bolt, Hex Head, 1/2-13 x 9-1/2 Long
58
7
206340
Lock Nut, 1/2-13
59
4
201682
Spacer, Black, .56 I.D. x .683 O.D. x 1.88 Long
60
4
201611
Bolt, Hex Flange, 5/16-18 x 3 Long
61
4
265601
Bolt, Carriage, 5/16-14 x 3-1/2 Long
62
4*
205528
Bolt, Hex Flange, 5/16-18 x 1 Long
63
2
904807
Elevator Tubes, Upper (Short)
64
1
207103
Pole Cap
65
1
201139
Bolt, Hex Head, 1/2-13 x 4-1/2 Long
66
2
201654
Triangle Plate
67
8
202862
Spacer, Plastic, 1/2 I.D., 1-1/4 Long
68
1
204837
Spring
69
1
Net
70
1
Rim
71
12
201219
Smart Clip, Net Holder
72
1
200118
Front Cover
73
1
211249
Label, Height and Moving
74
1
201568
Anchor Strap
75
2
200533
Board Spacer
*You may have extra parts with this model
