EN: Installation Sheet
Introduction
The VE1012PI is a PIR motion sensor with pet friendly optics.
Installation guidelines
The technology used in these detectors resists false alarm
hazards. However, avoid potential causes of instability such as
(see Figure 1):
•
Direct sunlight on the detector
•
Strong draughts onto the detector
•
Heat sources within the detector field of view
•
Animals above 35 cm (1 ft.) within the detector field of
view (see Figure 7)
•
Obscuring the detector field of view with large objects,
such as furniture
Installing the detector
Figure 8
(1) Standard connection
(factory default)
(2) Dual loop connection
1. Lift off the custom insert and remove the screw
(see Figure 2, item 1).
2. Using a screwdriver, carefully prise open the detector (see
Figure 2, items 2 and 3).
3. Fix the base to the wall between 2.3 m and 3.0 m (7.6 and
9.8 ft.) from the floor. For flat mounting use a minimum of
two screws (DIN 7998) in positions A. For corner-mounting
use screws in positions B or C (Figure 3). To install a pry-
off tamper, use position A or B.
4. Wire the detector (see Figures 3 and 8).
5. Select the desired jumper and DIP switch settings (see
Figure 6). See "Jumper settings" below for more
information.
6. Remove the blinders and add the stickers, if required (see
Figure 5 for an example).
For ceiling-mount applications that require a 90° coverage,
7.
use the SB01 swivel-mount bracket.
8. Close the cover.
9. Insert the screw and place the custom insert.
For EN 50131 Grade 3 installations, do not use mounting
position C.
Jumper settings
See Figure 6 for the jumper locations in the detector.
J1: Not used
J2: PIR enabling the LED
On: Enables the detector LED at all times (default).
Off: Puts the LED under control of the control panel and
disables the detector LED at all times (no memory feature).
P/N 146413999-2 (ML) • REV E • ISS 08MAR19
CP Control panel
WT Walk test
J3 and J4: Dual loop setting
This sets the alarm and tamper relays. It allows you to connect
the detector to any control panel. Use jumpers 3 and 4. See
Figure 8.
LED indication
Continuously on
PIR Red LED Alarm relay
Start up Closed
Low voltage Open (Alarm)
PIR intruder Open (Alarm)
alarm

Specifications

Detector
Signal processing
Range
Optical
Memory
Input power
Peak-to-peak ripple
Detector start-up time
Normal current consumption
Current consumption in alarm
Maximum current consumption
Mounting height
Target speed range
Alarm (NC) / Tamper relay
characteristic
Pry-off tamper
Alarm time
Operating temperature
Dimensions (H x W x D)
Relative humidity
Weight
IP/IK rating
Regulatory information
Manufacturer UTC Fire & Security Americas Corporation, Inc.
3211 Progress Drive, Lincolnton, NC, 28092, USA
Authorized EU manufacturing representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Normal blinking (1 Hz)
To reset
Automatically after 25 s
Apply correct voltage
Automatically after 3 s
PIR
V2E
12 m (39 ft. 4 in.)
9 curtains pet-friendly
No
9 to 15 VDC (12 V nominal)
2 V (at 12 VDC)
25 s
5.5 mA
1.2 mA
11 mA
2.3 to 3.0 m (7.6 to 9.8 ft.)
30 cm/s to 3 m/s (1 ft./s to 10 ft./s)
80 mA, 30 VDC
Optional
3 s
−10 to +55°C (14 to 130°F)
108 × 60 × 46 mm
(4.25 × 2.36 × 1.81 in.)
0 to 95% noncondensing
120 g (4.2 oz.)
IP30 IK02
