Davey Silensor Installations- Und Betriebsanweisungen Seite 2

Prior to using this pump you must ensure that:
• The pump is installed in a safe and dry environment
• The pump enclosure has adequate drainage in the event of leakage
• Any transport plugs are removed
• The pipe-work is correctly sealed and supported
• The pump is primed correctly
• The power supply is correctly connected
• All steps have been taken for safe operation
Appropriate details for all of these items are contained in the following Installation and
Operating Instructions. Read these in their entirety before switching on this pump. If you are
uncertain as to any of these Installation and Operating Instructions please contact your Davey
dealer or the appropriate Davey office as listed on the back of this document.
Your Davey Silensor
Congratulations on your purchase of a quality product from the Davey range of Pool and Spa
Equipment.
They should not be used for any other purpose without first consulting your Davey Dealer or
the Davey Customer Service Centre.
Davey design and build its own electric motors especially for its pumps. The matched motor
and "pumping end" are designed to provide the quietest operation while delivering maximum
water flow.
Davey's innovative water cooled motor incorporates manual overload protection with a built-in
automatic thermostat designed to protect the motor from overheating. This protection will also
prevent 'dry run' damage.
Every Davey Silensor is thoroughly tested against a number of pressure, voltage, current and
mechanical performance parameters. Davey`s advanced pump manufacturing technology
provides reliable and efficient pumping performance that lasts and lasts.
Location
The pump should be located as close to the water as practicable and mounted on a firm base
in a well drained position, high enough to prevent any flooding. It is the installer's/owner's
responsibility to locate the pump such that the nameplate can be easily read and the pump
can be readily accessed for service.
Return to
Figure 1.
Pool
50/63mm
Suction line
50/63mm
250mm
ELBOW
Suction line
50/63mm
152mm
MINIMUM
76mm
MINIMUM
Return to
Figure 2.
Pool
50/63mm
