IR Illuminator and brightness. In VIDEO mode the display shows the following information:
IR Illuminator power level – shown by the corresponding icon -
. If the IR Illuminator is off, the icon is not displayed.
Brightness level.
Brightness level (from 0 to 20) is displayed only when adjusting
brightness.
Wi-Fi
Wi-Fi connection is shown in the top right corner of the display.
Built-in microphone
Activation of the built-in microphone is shown in the top right
corner of the display.

PHOTO MODE

Photo Mode is shown by icon on the display.
* The counter of available photos is displayed when the
number of photos is 999 or less.
Photos are saved into the internal Flash memory.
The following functions are displayed in PHOTO Mode:
IR Illuminator
Brightness
Full magnification
Wi-Fi
Note: sound is not recorded in Photo Mode.
13
Available Brightness
recording time adjustment
VIDEO
9x
01:42 15
mode
04:23pm
Current time
ZOOM SOUND
VIDEO mode
counter*
999
9x
04:23pm
Current time
REVIEW MODE is designed to review photo and video files (saved in the internal Flash memory) on the
display.
File display order. Upon activation of Review Mode, the display always shows the last recorded file.
Mode indication on the display. Along with the image itself the display shows the following information:
File type icon: photo or video .
Video clip length – shown as mm:ss. File counter –
shown as x/y (common for photo and video files) –
x – number of running file.
y – total number of files.
REVIEW Mode – Photo
REVIEW Mode – Video
Page navigation (left-right).
Resolution of current (displayed) file.
"PLAY" and "PAUSE" indicators for video clip
File deletion indicator
Date and time of file recording
Mode
REVIEW-PHOTO
File counter
2/123
File navigation File navigation
arrow (left) arrow (right)
2016.08.05 Time and date
22:18
Photo resolution 960p of photo file
Delete current file
Video duration
00:05
Video review mode
File counter
2/123
File navigation
File navigation
arrow (right)
arrow (left)
Time and date
Х 2016.08.05
of video file
480p
Photo resolution 22:18
Play current file Delete current file
