VIEWEG
8 Disposal
At the end of its service life, dispose of the controller in accordance with the applicable
local regulations .
EN
9 Technical data
Outer dimensions (W x H x D)
weight
Power supply
Internal voltage
Dispensing duration
Compressed air input
Compressed air Output
Digital display
Programs
Available models
10 Technical connections
10.1 Foot switch
Assignment:
10.2 I/O-Port
Type:
Assignment:
Supply voltage:
Electrical parts cannot be disposed of with household waste .
According to Directive 2012/19/EU on Waste Electrical and Electronic
Equipment (WEEE), electrical equipment must be returned to the
collection points set up for this purpose in order to be reused .
Closing contact between pin 1 + 3 starts the dispensing process
15-pin Sub D female 2 rows
see following table
The device has an internal 24V voltage supply which is
provided at pin 2 and 3 with max . 100 mA, e . g . for an external
sensor supply
Operating Instructions DC 300
235 x 210 x 75 mm
approx . 1 . 3 0 kg
85 – 264 V AC 50/60 Hz
24 V DC
0 . 0 1 to 9999 sec .
0 to 7 bar ( Display: Digital )
Material or dispensing pressure
DC 315:
0 - 1 bar
DC 370:
0 - 7 bar
7 segment 4-digit display
9 memory slots
DC 315:
0 - 1 bar
DC 315-I/O: 0 - 1 bar and I/O-Port
DC 370:
0 - 7 bar
DC 370-I/O: 0 - 7 bar and I/O-Port
30
