I. Parts List
II. Characteristics
I. PARTS LIST
1. Wall mounting plate
2. Pin of pivot
3. Handle
4. Window
5. Hose stop
II. CHARACTERISTICS
Reference
Model type
Main hose length
Intake hose length
Inner hose diameter
Pressure max.
Hose
Housing
Dimensions (approx.) 21x12x8.5 cm
Weight (approx.)
III. Safety instructions
IV. Getting Started
Fig. 1
733976 / PRDATA10
ZW02-9
10 m
1,5m
∅12,5mm (1/2")
10Bar
PVC
PP
5,5 kg
V. Operation
VI. Maintenance and Storage
Fig. 2
6. Hose
7. Right housing
8. Left housing
9. Intake hose
734226 / PRDATA15
ZW01-15C
15 m
1,5m
∅12,5mm (1/2")
10Bar
PVC
PP
24x13x10.5 cm
9 kg
734116 / PRDATA20
ZW01-20B
20 m
1,85m
∅12,5mm (1/2")
10Bar
PVC
PP
28x17x15.5 cm
10 kg
