Technical Data - eKey home (net) integra Montageanleitung

MONTAGE ekey home Aufputz
COUNTER-SINKING AND MOUNTING OF THE EKEY HOME (NET)
INTEGRA CONTROL PANEL
COUNTERSINKING FOR THE
Ausfräsung für die Inneneinheit integra
INTEGRA INDOOR UNIT
X
< >
OK
273.00
Fräsbreiten: 18mm, 20mm oder 24mm
Widths of cuts: 18mm, 20mm or 24mm
DOOR LEAF
Türblatt
Hole for the fastening
Bohrungen f. Befestigungsschrauben
(optional) screws (optional)
30.0
254.00
Outlet for the cable lead
233.25 (from the outdoor unit, motorised
Auslass für Kabelzuführung
lock and main supply cable, the
(von Außeneinheit, Motorschloss und Hauptzuleitung,
position of the recess can be
die Position der Ausnehmung ist frei wählbar)
freely selected)
min. 8mm

TECHNICAL DATA

Technical data
ekey home (net) fingerprint
scanner integra
Power supply
Power input
Temperature range
Memory
Security
Protection class
Speed
Life cycle Fingerprint scans
Technical data ekey home (net)
integra control unit
Power supply
Power input
Relays
RELAY
Switching power
Load voltage(Peak AC)
ON resistance (max.)
OFF state leackage current
Turn On time
Turn Off time
Temperature range
Protection class
Digital inputs
Maximum current to X6 PIN 1 (only
with Integra)*
1 relay (2 relays area available in the ekey home 2 and PC version) is available for
controlling external devices. The programming is carried out via the programming
menu. Relay 1 has a potential-free or non-isolated closing contact which can be
configured via JP1.(if JP1 is not assembled, Relay 1 works non isolating) Relay 2
is generally potential-free and can be configured via JP2 as an opening or closing
contact. The maximum switching capacity is 42V / 2A.
The connection cable between the control panel and the fingerprint scanner is to
be laid separately from the electrical installations of the building, as these signals
produce a low-voltage area which can be impaired by adjacent live cables.
The connections do not have reverse polarity protection! An incorrect
electrical connection of the system can cause damage to the device.
The creation of the electrical connection and the connection to the mains
can only be carried out by specialists!
Unit ekey home integra
ekey net integra
V AC 8-24
V DC 8-30
W approx. 1
°C -40 to +85
Fingerpts home: 99
net: 40/200/2000
-6
FAR 1x 10
-2
FRR 1.4x 10
IP 54 (front)
S 1-4
max. 4 mill.
ekey home integra 2,
Unit ekey home
pc
integra
ekey net integra
VAC 8-24 8-24
VDC 8-30 8-30
W approx. 1 approx. 1
Number 1 2
42VDC(AC)/2A 42VDC(AC)/2A
V 60 60
0,12 0,12
A 1 1
ms 1.5 1.5
ms 0.5 0.5
°C -40 to +85 -40 to +85
IP 40 (front) 40(front)
1 1
A 3 3
