 4 independent channels
 soft-start function prevents damage from large charge current while
charging
 automatic cut off when the battery is fully charged
 precision cut-off voltage at 4.2 V
 overheat protection
 LCD displays the status of each battery in real time
 Use high power intelligent step-down DC - DC circuit, greatly reduce the
energy loss
 reverse-polarity and short circuit protection
 fireproof housing
 0 V function to reactivate over-discharged batteries
5. Overview
Refer to the illustrations on page 2 of this manual.
1 charging channel
2 charging current
Charging State and Battery Power Indication
 When the battery voltage reaches the next stage, one more bar will be
added. No battery level icon will be displayed in the corresponding
channel when the charger is in one of the following conditions:
no battery is placed in the channel
o
short circuit
o
battery voltage < 1.0 V
o
battery is reversed or poorly connected
o
V. 01 – 06/02/2015
charging
20 % - 40 %
60 % - 80 %
100 %
VLEVP4
3 power indicator
4 charging voltage
4
0 % - 20 %
40 % - 60 %
80 % - 99 %
