1.
Correctly identify each pole section.
I.D. Label
Bounce middle pole (2) into top pole section (1) using a wood scrap as shown until top
2.
pole no longer moves toward pole identification mark on middle pole.
THE IDENTIFICATION STICKER IS
LOCATED 5" FROM THE END OF THE
POLE. WHEN PROPERLY POUNDED
TOGETHER, THE POLE SECTIONS
SHOULD HAVE A 3-1/2" MINIMUM
OVERLAP, LEAVING 1-1/2" BETWEEN
THE OVERLAPPING POLE AND THE
IDENTIFICATION STICKER.
IDENTIFICATION
STICKER
1
IDENTIFICATION
STICKER
WARNING
LABEL
CAUTION!
2
IDENTIFICATION
5"
2
1-1/2"
1
I.D. Label
2
POLE SECTIONS
SHOULD HAVE A
3-1/2" (9 CM)
POLE
MARK
9
1
NOTE:
MINIMUM
OVERLAP.
04/06
3
2
1
WOOD SCRAP
(NOT SUPPLIED)
ID#
M6011141
