Connection of one computer to one 5K DisplayPort
You can set up one 5K display by using both video output ports of the
IB-DK2245AC (2x DisplayPort
Connect your supported 5K monitor to both DisplayPort
DisplayPort
cables (not included).
™
Note: The DockingStation is compatible with most 5K-enabled monitors on the market.
Please refer to
http://www.displaylink.com/downloads
better compatibility.
Connection of one computer to multiple monitors
(optional, multiple DockingStations necessary)
1.
Connect a compatible computer to the powered DockingStation (Dock 1) as shown
as above.
2.
Connect a USB 3.0 port (USB Type-A or USB Type-C
Type-C
host interface of a second DockingStation (Dock 2, not included) via a
™
supported USB 3.0 cable (not included).
3.
Connect monitors to both docks via standard HDMI
included).
Note: The device can work with any compatible DockingStation to set up similar connec-
tions as shown as in the drawing below.
A third DockingStation in a row is also also supported (up to six monitors then), but keep in
mind the lower performance, because of the USB 3.0 bandwidth limitation).
Manual IB-DK2245AC
).
™
monitor
™
interfaces by using certified
™
to download the latest driver for
port) of Dock 1 to the USB
™
and DisplayPort
®
cables (not
®
