Tempo 180XL Handbuch

Read and understand all of the
instructions and safety information
in this manual before operating or
servicing this tool.
Description
The Tempo Communications 180XL Visual Fault
Locator is used to visually locate loss locations
such as Macrobends, bad connectors, and other
fiber discontinuities. Fiber continuity can also be
visually confirmed.
Safety
Safety is essential in the use and maintenance
of Tempo tools and equipment. This instruction
manual and any markings on the tool provide
information for avoiding hazards and unsafe
practices related to the use of this tool. Observe all
of the safety information provided.
Purpose of this Manual
This manual is intended to familiarize all personnel
with the safe operation and maintenance
procedures for the Tempo Communications 180XL
Visual Fault Locator.
Keep this manual available to all personnel.
Package Contents
1 Visual Fault Locator
1 Instruction manual
1 Soft carry case
52068675 REV3
INSTRUCTION MANUAL
180XL Visual Fault Locator
© 2019 Tempo Communications Inc.
Important Safety Information
CAUTION
Do not look directly into the output port when the
instrument is ON. Never use a viewing instrument
such as a magnifier or microscope to view the free
end of any optical fiber connected to the 180XL.
The use of viewing on active fibers can focus an
intense laser beam onto the retina of the eye,
resulting in permanent damage or blindness.
Always aim the free end of an active fiber at a non-
reflective surface.
Users should always cover the output port with the
dust cap when the instrument is not in use.
Do not discard this product or throw away!
For recycling information, go to
www.TempoCom.com.
All specifications are nominal and may change as
design improvements occur. Tempo Communications
shall not be liable for damages resulting from
misapplication or misuse of its products.
KEEP THIS MANUAL
LASER LIGHT
DO NOT STARE INTO BEAM
1 mW max at 640-660 nm
CLASS 2 LASER PRODUCT
EN 11/19
