Electrical installation

2
PE
N L1
1 2
N PE L1 1 2
Controller supply line
(pre-installed)
5
N Neutral conductor
PE Protective earth
conductor
L1 Outer conductor
3
1 Error message
230 V / charge
prompt
2/3 Floating
3
Information
In the event of a power
failure, the relay at con-
tact 2/3 is open.
Information
Relay assignment can be se-
lected during commissioning.
Selection of NO (normally
open) or NC (normally closed)
