3) INTERNAL COMPONENTS

1
3
2
4
Crown pad
Cheek pads
3.1) Removing/fitting cheek pads
To remove the cheek pads, hold them in front near the
chin guard and pull them in the direction of the arrow
to free them from the press studs (1). Slide the plastic
flap out of its position and remove the cheek pads (2).
To refit the cheek pads, slide them into the helmet,
slide the plastic flap into position on the side of the
helmet (3) and fasten them into place with the press
studs (4).
Make sure that the cheek pads are properly fastened
to the helmet.
13
