7 Specifications

Amplifier power
Rated power: � � � � � � � � � � � � � 50 W
Peak power: � � � � � � � � � � � � � � 100 W
Speaker
Bass speaker: � � � � � � � � � � � � � ⌀ 30 cm (12")
Horn tweeter: � � � � � � � � � � � � � ⌀ 2�5 cm (1")
Frequency range: � � � � � � � � � � � � 50 – 20 000 Hz
Wireless receiver sections: � � � � � 2
Wireless transmitter sections: � � � 1
Transmitting power: � � � � � � � � ≤ 10 mW
Frequencies transmitted and received
Channel Frequency Channel
01 863�1 MHz 09
02 864�1 MHz 10
03 863�6 MHz 11
04 864�6 MHz 12
05 863�3 MHz 13
06 864�3 MHz 14
07 863�8 MHz 15
08 864�8 MHz 16
Wireless transmission range: � � � approx� 30 m
Input sensitivity
MIC 1, MIC 2
(XLR jacks, top): � � � � � � � � � � � 24 mV
Microphone input of channels 1– 3
(XLR jacks, rear): � � � � � � � � � � � 4�5 mV
JACK-LINE, 6�3 mm jack: � � � � � 150 mV
AUDIO IN, RCA: � � � � � � � � � � � 400 mV
Pin configuration of the microphone inputs, XLR
Channels 1 and 2:
1 ground
2 1
2 signal +, +24 V phantom power
3
3 signal −, +24 V phantom power
1 ground
2 1
2 signal +, +24 V phantom power
3
3 signal −, +24 V phantom power
Channel 3:
1 ground
2 1
2 signal +
3
3 signal −
Pin configuration of the line inputs, 6�3 mm jack:
S T
S
T
All rights reserved by MONACOR
manual may be reproduced in any form or by any means for any commercial use.
Output LINE OUT, REC: � � � � � � � 320 mV
Equalizer
LOW: � � � � � � � � � � � � � � � � � � � ±12 dB at 60 Hz
MID: � � � � � � � � � � � � � � � � � � � � ±7 dB at 1 kHz
HIGH: � � � � � � � � � � � � � � � � � � � ±12 dB at 15 kHz
XLR jack for the gooseneck light:
2 1
3
Power supply: � � � � � � � � � � � � � � 230 V/ 50 Hz
Power consumption: � � � � � � � � � 135 VA max�
Frequency
Ambient temperature: � � � � � � � � 0 – 40 °C
863�2 MHz
Dimensions
864�2 MHz
Width: � � � � � � � � � � � � � � � � � � 800 mm
863�7 MHz
Height: � � � � � � � � � � � � � � � � � 850 – 1250 mm
864�7 MHz
Depth: � � � � � � � � � � � � � � � � � � 570 mm
863�4 MHz
Weight: � � � � � � � � � � � � � � � � � � � 52 kg
864�4 MHz
863�9 MHz
864�9 MHz
ground
signal
Subject to technical modification .
INTERNATIONAL GmbH & Co. KG. No part of this instruction
®
1 ground
2 +12 V, 0.5 A max. (6 W)
