Logitech ® QuickCam ® Installation
3

Camera Setup

During the Camera Setup step of the installation process, you will be prompted to connect the camera to a USB
port on your computer. Important: Do NOT connect the camera until you are prompted to do so
4
Position Your Camera, Microphone, and Speakers
Your camera comes with Logitech ® RightSound ™
technology. The following steps will ensure the best possible audio
performance:
1. Position your camera in the middle of your monitor
for optimal eye contact.
2. Position your camera's microphone no more than 3 feet
(1 m) away from you and point it toward you.
3. Position your speakers (if used) at least 12 inches (30 cm)
away from your microphone to reduce feedback, and
then angle your speakers away from your microphone.
Tip Do not place objects between you and the microphone.
 English
echo-cancellation
Flatten out legs
to place camera
on any flat surface.
Logitech ® QuickCam ® Installation
5
The Audio Tuning Wizard
The first time that you start QuickCam, you are guided through the Microphone/
Speaker Setup Utility and Audio Tuning Wizard that lets you do the following:
• Select the audio input device (microphone)
and audio output device (speakers).
• Enable Acoustic Echo Cancellation (AEC)—recommended.
• Specify microphone input volume and speaker output volume.
• Test audio settings.
Tip
To change these settings later, in the QuickCam
click the Settings button and then click the Audio tab.
® software,
English
