Hand-held stapler set
 I ntroduction
Q
Before using the product for the first time,
take time to familiarise yourself with the
product first. Read the following operation
instructions and safety instructions carefully. Only
use the product as described and for the designated
areas of application. Please keep these instructions
in a safe place. If you hand this product on to a third
party, you must also pass on all documents relating
to the product.
 ProperUse
Q
The stapler gun is intended exclusively for stapling
cardboard, leather, cloth (textile or natural fibres)
or similar lightweight materials on to hardwood, soft-
wood, chipboard or similar plywood-type materials.
Any use other than previously mentioned or any
product modification is prohibited and can lead to
injuries and / or product damage. The manufactur-
er is not liable for any damages caused by any use
other than for the intended purpose. The product is
not intended for commercial use.

 Descriptionofparts
Q
1 Operating handle
Staple pusher
2
Hook
3
Magazine
4
5 Side wing
6 Staple eject opening
7 Adjusting screw
 SupplyScope
Q
Immediately after unpacking, check that the delivery
is complete and that the product and all its parts are
in perfect condition. Do not under any circumstances
assemble the product if the delivery is incomplete.
53466_Handtacker_Content_LB4.indd 5
Includeditems
Q
1 x Stapler gun
200 x Flat crown staples (8 mm)
200 x Round crown staples (12 mm)
200 x T-nails (10 mm)
1 x Operating instructions
Staples/nails
Q
Note: The precision components of the device are
designed to use the following standard, widely
available staples and nails:
A
Type
(mm)
Flat crown 4 - 14
staples
B
A
C
Round crown 10 - 12
staples
B
A
C
T-nails 10 - 14
B
A
C
Introduction
B C
(mm) (mm)
11.2 - 11.5 1.1 - 1.3
6.2 - 6.5 1.1 - 1.3
1.6 - 2 1.1 - 1.3
